5-axis simultaneous machining for complex geometries

Receive 2-4 weeks from order

Overview

The IRON CORE i5 Pro is a heavy-duty 5-axis milling platform engineered for labs requiring reliable metal production without compromise. Built around a one-piece cast iron structure, it ensures maximum rigidity and vibration control, essential for consistent, high-precision machining of demanding dental materials. This machine is designed to handle continuous workloads with thermal stability and mechanical consistency, making it ideal for real production environments.

Key Features

The IRON CORE i5 Pro offers a range of features that enhance its performance and usability in dental labs.

One-piece cast iron frame for maximum rigidity and vibration damping.
5-axis simultaneous machining for complex geometries.
High-power water-cooled spindle for stable long-run performance.
Smart servo control system for consistent cutting behaviour.
User-friendly interface with guided workflow for straightforward operation.
Built for continuous production with reduced rework.

Technical Specifications

Below are the detailed specifications of the IRON CORE i5 Pro.

Machine Type	5-axis dental milling machine
Structure	One-piece cast iron frame
Spindle	Power: 2.5 kW, Type: Water-cooled, Speed: up to 60,000 rpm
Axis Movement	5-axis simultaneous machining, A-axis: ±25°, B-axis: 360°
Accuracy	Processing accuracy: < 0.01 mm
Drive System	Smart servo motor system
Interface	Integrated touchscreen control (approx. 15-inch)
Cooling System	Water-cooled spindle for thermal stability
Applications	Implant bars, Custom abutments, Metal frameworks, Precision dental components
Material Compatibility	Titanium alloys, Zirconia, PMMA, Wax, PEEK

Applications

The IRON CORE i5 Pro is versatile and can be used for various applications, including milling implant bars, custom abutments, and complex metal restorations. It is designed to meet the demands of high-volume dental labs, ensuring precision and efficiency in every task.
